ATEX Series --- EXH8R
Industry Headlamp Datasheet
PACKAGING INFORMATION | |
|---|---|
Type of packaging | Sleeve Box |
Scope of delivery | 1 set of rechargeable batteries,
Charging base, Power supply |
Item No. | 501018 |
Dimensions W x H x D [cm] | 26.6 x 16.6 x 10.1 |
Gross weight [g] | 985 |
TECHNICAL DATA | |
|---|---|
Head diameter [mm] | 41 |
Weight incl. batteries [g] | 342 |
Weight without batteries [g] | 266 |
Focus function | Yes |
Head material | PC |
Tube material | PC |
Optic | Plastic lense (PMMA) |
Headband material | Elastic fabric |
Headband type | Side overhead headband |
Head movement type | Stepless movement |
Head movement angle [°] | 55 |
Headband specifications | Detachable,
Elastic,
Rubberised back,
Washable |
POWER SUPPLY | |
|---|---|
Power source type | Rechargeable battery |
Battery quantity | 1 |
Battery type | Li-ion |
Battery description | 1×18650 Battery Pack 3.7V |
Total battery voltage [V] | 3.7 |
Total battery capacity [mAh] | 3250 |
Total battery energy [Wh] | 12 |
Rechargeable | Yes |
Charging time [min] | 660 |
Charging technology | Internal |
Energy status indicator | Charge Indicator |
EXPLOSION PROTECTION | |
|---|---|
ATEX Certificate | Baseefa17ATEX0157 |
IEC Ex Certificate | IECEx BAS18.0008 |
Ex marking | II 2G Ex ib op is IIC T4 Gb II 2D Ex ib op is IIIC T135°C Db |
Ex-Zone Gas | 1 |
Gas Group | IIA ,IIB, IIC |
Temperature Class Gas | T4 |
Ex-Zone Dust | 21 |
Dust Group | IIIA, IIIB, IIIC |
Temperature Class Dust | 135 °C |
FURTHER SPECIFICATIONS | |
|---|---|
IP class | IP66 |
Drop test (drop height) [m] | 1 |
Working temperature range [°C] | -20 to +40 |
LIGHT FUNCTIONS | |
|---|---|
Low Power, Power | |
LIGHT SOURCE | |
|---|---|
Amount LEDs | 1 |
Color | White |
Color temperature [K] | 6000 to 8000 |
Color rendering index (CRI) | 65 |
LIGHT VALUES | ||||
|---|---|---|---|---|
ANSI – Energy Saving | Boost | Power | Mid Power | Low Power |
Light output [lm] | 200 | 45 | ||
Beam distance [m] | 130 | 60 | ||
Run time [h] | 10 | 45 | ||
SWITCH | |
|---|---|
Magnetic Switch, Rotary Switch | |
FEATURES | |
|---|---|
Rear light | |
TECHNOLOGIES | |
|---|---|
Advanced Focus System | |
EXH8R- The Ledlenser EX series
Chin up if you work in areas with dangerous gases or dust. After all, despite the rugged, dustproof housing protected against powerful water jets (IP 66) it’s extremely comfortable. Plus it’s the first rechargeable headlamp with our patented Advanced Focus System. It delivers up to 45 hours of custom light for any application and includes a charging cradle to easily recharge it at any time.
Magnetic Switch for easy operation with gloves and protective equipment
First Ex lamp for Ex-Zone 1/21 with patented Advanced Focus System
Focusable
Dustproof and protected against powerful water jets (IP 66)
Red rear light as a position marker
Light Functions
- Power – high light output for every situation
- Low Power – economical light for long battery life, glare-free reading and working
Switches
- Magnetic Switch – with two off positions for easy operation while wearing gloves and protective equipment
EX - Rating
- Ex-Zone 1/21 -Working areas in which explosive atmospheres in the form of flammable gases, vapors or dust clouds prevail occasionally.
Special Function
- Ex-Zone 1/21 -Working areas in which explosive atmospheres in the form of flammable gases, vapors or dust clouds prevail occasionally.
- Rear Light – A red backlight so that you can also be seen from behind for added safety
- Adjustable, Washable Headband – With an anti-slip rubber grip
IP-Class
- IP66 – Protection for submersion in Water resistant against powerful jets
- IP68 – Resistant to submersion up to a maximum depth of 1.5m underwater for up to thirty minutes.
WITH ATEX SERIES, THE JOBS ARE SAFE. AT LEAST WHEN IT COMES TO THE LIGHT.
If you work in explosive environments, safety is extremely important when it comes to using electronics. Safety, which is defined in the ATEX directives of the European Union. Ledlenser EX and iL series lamps meet these standards in every aspect. Designed specifically for contact with explosive gases, vapors and dust in the best possible groups IIC and IIIC. They feature maximum dust protection, are protected from water and ATEX and IECEx approved.
Yet both lines – in compliance with the ATEX operating directives – are designed for different types of explosion hazards. The EX series is suitable for use in areas where explosive atmospheres are frequently present (zones 0, 1, 20, or 21), and the iL series for zones 2/222. So you’ll find the perfect lamp for any environment.
