Description
H8R Datasheet
PACKAGING INFORMATION | |
---|---|
Type of packaging | Box |
Scope of delivery | quick user guide, 1 set of rechargeable
batteries, USB cable |
Item No. | 500853 |
Dimensions W x H x D [cm] | 13.5 x 11.5 x 10
|
Gross weight [g] | 340 |
TECHNICAL DATA | |
---|---|
Head diameter [mm] | 36 |
Weight incl. batteries [g] | 158 |
Weight without batteries [g] | 110 |
Focus function | Yes |
Head material | Aluminum alloy |
Housing material | PC |
Optic | Lense (PMMA) |
Headband material | Elastic fabric |
Headband type | Side headband |
Head movement type | Stepped movement |
Head movement angle [°] | 65 |
Headband specifications | Detachable,
Elastic,
Washable |
POWER SUPPLY | |
---|---|
Power source type | Rechargeable battery |
Battery quantity | 1 |
Battery type | Li-ion |
Battery technology | 18650 3.7V |
Total battery voltage [V] | 3.7 |
Total battery capacity [mAh] | 3400 |
Total battery energy [Wh] | 12.58 |
Rechargeable | Yes |
Charging time [min] | 360 |
Charging technology | Internal |
Energy modes |
Energy Saving |
Energy status indicator | Charge Indicator, Low Battery Warning |
Usable batteries | None |
FURTHER SPECIFICATIONS | |
---|---|
IP class | IPX4 |
Drop test (drop height) [m] | 2 |
Working temperature range [°C] | -20 to +40 |
LIGHT FUNCTIONS | |
---|---|
Power, Mid Power, Low Power |
LIGHT SOURCE | |
---|---|
Amount LEDs | 1 |
LED type | Xtreme LED |
Color | White |
Color temperature [K] | 6000 to 8000 |
Color rendering index (CRI) | 70 |
LIGHT VALUES | ||||
---|---|---|---|---|
ANSI – Energy Saving | Boost | Power | Mid Power | Low Power |
Light output [lm] | 600 | 250 | 10 | |
Beam distance [m] | 150 | 100 | 20 | |
Run time [h] | 10 | 15 | 120 |
SWITCH | |
---|---|
Front Switch |
FEATURES | |
---|---|
Rear Light, Transportation Lock |
TECHNOLOGIES | |
---|---|
Advanced Focus System, Rapid Focus, Smart Light Technology,
Temperature Control System |
The Perfect Light for Everyday Use
With this headlamp you always have your hands free for your project, your hobby or just in case. Because the H8R adjusts perfectly to your head, thanks to its ergonomic design and is easy to handle. That way you always have the best view and even better: the red backlight makes sure you’re being seen by everyone else. And one more highlight: you can simply charge it anywhere in the world via USB 3.0 – a great feature especially on the road.
