Description
MH10 Datasheet
PACKAGING INFORMATION | |
|---|---|
Type of packaging | Window Box |
Scope of delivery | 1 set of rechargeable batteries,
Filter set,
Pouch,
USB cable |
Item No. | 501513 |
Dimensions W x H x D [cm] | 15 x 12 x 8.5
|
Gross weight [g] | 377 |
TECHNICAL DATA | |
|---|---|
Head diameter [mm] | 36 |
Weight incl. batteries [g] | 158 |
Weight without batteries [g] | 110 |
Focus function | Yes |
Head material | Aluminum alloy |
Housing material | PC |
Optic | Plastic lense (PMMA) |
Headband material | Elastic fabric |
Headband type | Side headband |
Head movement type | Stepped movement |
Head movement angle [°] | 65 |
Headband specifications | Detachable,
Elastic,
Washable |
POWER SUPPLY | |
|---|---|
Power source type | Rechargeable battery |
Battery quantity | 1 |
Battery type | Li-ion |
Battery replaceable | Yes |
Total battery voltage [V] | 3.6 |
Total battery capacity [mAh] | 3200 |
Total battery energy [Wh] | 11.52 |
Rechargeable | Yes |
Charging time [min] | 270 |
Energy modes | Constant Current,
Energy Saving |
Energy status indicator | Charge Indicator,
Low Battery Warning |
FURTHER SPECIFICATIONS | |
|---|---|
IP class | IP54 |
Drop test (drop height) [m] | 2 |
Working temperature range [°C] | -20 to +40 |
LIGHT FUNCTIONS | |
|---|---|
Low Power, Power, Mid Power | |
LIGHT SOURCE | |
|---|---|
Amount LEDs | 1 |
LED type | Xtreme LED |
Color | White |
Color temperature [K] | 6000 to 8000 |
Color rendering index (CRI) | 65 |
LIGHT VALUES | ||||
|---|---|---|---|---|
ANSI – Energy Saving | Boost | Power | Mid Power | Low Power |
Light output [lm] | 600 | 250 | 10 | |
Beam distance [m] | 150 | 100 | 20 | |
Run time [h] | 10 | 15 | 120 | |
a | ||||
ANSI – Constant Current | Boost | Power | Mid Power | Low Power |
Light output [lm] | 400 | 10 | ||
Beam distance [m] | 130 | 20 | ||
Run time [h] | 6 | 70 | ||
SWITCH | |
|---|---|
Front Switch
| |
FEATURES | |
|---|---|
Rear light , Transportation lock | |
TECHNOLOGIES | |
|---|---|
Advanced Focus System, Smart Light Technology, Temperature Control
System, Rapid Focus | |
Ledlenser Outdoor Series Headlamp
The MH10 is the lightest Ledlenser headlamp of its brightness levels. It is equipped with a red taillight as well as color filters for various different uses.
Its USB 3.0 charging system offers an international standard for comfortably charging your Ledlenser. Perfect for hunters, fishers, hikers and everyone who is looking for extremes outside.
- Eco-friendly and convenient – cutting-edge battery technology for the fastest charging time via USB 3.0 in any situation
- Extra safety – red rear light
- Comfortable – best weight-to-lumen ratio of all Ledlenser headlamps
Better close-up and distance view – pivoting head with a continuous focus feature - Constant Light Mode – for special constant LED-Power
Ledlenser MH10 Comparison
Wear with the included Colour Filter set
1. Light Functions
- Power – high light output for every situation
- Mid Power – medium light output for every situation
- Low Power – economical light for long battery life, glare-free reading, and working
2. Special functions
- Advanced Focus System (AFS) – for efficient, precise flood and spotlighting
- Rapid Focus – With one hand and one movement to achieve seamless transition from close to far and all points in between.
- Smart Light Technology – allows individual ranges of functions to be programmed to different touch and switch combinations
- Temperature Control System – Regulates heat produce by the LED to prevent overheating
- Energy modes – Constant current & Energy Saving
3. IP-Class
- IP54 – Protection against contamination from limited amounts of dust and other particles.
MH Series
The Ledlenser Outdoor-Series
Brightness in your Hands. Darkness under control.
Not only do mountain hikers have high standards when it comes to flashlights, headlamps and lanterns – so do campers, geocachers, hunters, anglers and many other outdoors fans.
Lights from Ledlenser meet precisely these high standards of quality in terms of functionality and design. We call it “technology engineered in Germany”.
